FGK25 Sprag One Way Bearing 25mm ID 42mm OD 70Nm Torque

Name: FGK25 Sprag One Way Bearing 25mm ID 42mm OD 70Nm Torque
Brand: Changzhou Tianniu Transmission Equipment Co., Ltd
SKU: FGK 25
Price: 7.10 USD
Availability: InStock

Productgegevens

Plaats van herkomst: Jiangsu, China

Merknaam: SUMA

Modelnummer: FGK 25

Betaling & het Verschepen Termijnen

Min. bestelaantal: 1

Vind de beste prijs

Contact opnemen

Specificaties

Beschrijving

Specificaties

Markeren:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                            25mm one way sprag bearing, 42mm OD one way bearing, 70Nm torque one way bearing


Precisie -beoordeling:	P6	Typ van afdichting:	Open
Buitendiameter:	42 mm	Binnendiameter:	25 mm
Hoogte:	48 mm	Materiaal:	Chroomstaal GCr15
Koppel:	70 nm	Boordiameter:	25 mm
Koppelcapaciteit:	70 nm	Innerlijke racesnelheid:	530r/min
Buitenracesnelheid:	3800R/min	Dynamische belasting:	6300N
Statische belasting:	3450N	Gewicht:	0.11kg
Type:	Sprag

Precisie -beoordeling:	P6
Typ van afdichting:	Open
Buitendiameter:	42 mm
Binnendiameter:	25 mm
Hoogte:	48 mm
Materiaal:	Chroomstaal GCr15
Koppel:	70 nm
Boordiameter:	25 mm
Koppelcapaciteit:	70 nm
Innerlijke racesnelheid:	530r/min
Buitenracesnelheid:	3800R/min
Dynamische belasting:	6300N
Statische belasting:	3450N
Gewicht:	0.11kg
Type:	Sprag

Beschrijving

FGK25 Sprag One Way Bearing 25mm ID 42mm OD 70Nm Torque

FGK 25 Sprag Clutches Freewheels One Way Bearing FGK25

Product Description

Internal Freewheels FGK are sprag freewheels with bearing support in the dimensions of the needle bearing series 59.

Applications

Backstops
Overrunning Clutches
Indexing Freewheels

Specifications

Model	FGK25
Material	Gcr15
Bore diameter	25mm
Outer diameter	42mm
Height	48mm
Torque capacity	70Nm
Inner race overrun speed	530r/min
Outer race overrun speed	3800r/min
Application	Automobiles, motorcycles, power tools, textile machines
Package	Carton package / Wooden package
Delivery time	5-7 days
Payment terms	TT, L/C, D/P, D/A, Western Union, Paypal

Technical Specifications

Size	Nominal Torque (Nm)	Max. Speed (Inner/Outer)	Load Rating (Dynamic/Static)	Bore (mm)	D (mm)	K (mm)	L (mm)	Weight (kg)
FGK20	50	5,500/4,000	5,600/4,400	20	37	42	23	0.09
FGK25	70	5,300/3,800	6,300/5,300	25	42	48	23	0.11
FGK30	95	5,000/3,500	7,700/5,500	30	47	54	23	0.13
FGK35	200	4,600/3,200	8,200/8,500	35	55	63	27	0.20
FGK40	310	4,200/3,000	8,650/8,300	40	62	70	30	0.30
FGK45	370	3,800/2,500	9,200/9,650	45	68	76	30	0.34
FGK50	460	3,400/2,200	9,650/10,000	50	72	80	30	0.36
